FlexStep is an innovative, compact accessibility solution, able to act as ordinary steps and a lift for wheelchair users.
FlexStep has a wide range of design and configuration options, making it easy to integrate into existing rooms and situations.
FlexStep has been tested and approved by a third party as compliant with the standards CSA B355:2019 - Platform Lifts and Stair Lifts for Barrier-free Access and ASME A18.1:2020 - Safety Standard for Platform Lifts and Stairway Chairlifts.
Fixed steps are available in step widths of 700 mm, 800 mm, 900 mm or 1,000 mm. With its versatile design and configuration options, it seamlessly integrates into existing spaces.
An adaptable space-saving solution
If you're struggling to accommodate both a flight of stairs and a stairlift, FlexStep could be the solution. If finding space for both a flight of stairs and a stairlift is proving problematic, a FlexStep stairlift could be the answer you are looking for. This clever 2-in-1 lift and staircase solution gives you both stairs and a stairlift even in the tightest places; if you have room for stairs, there’s room for a FlexStep stairlift.
FlexStep Benefits:
2-In-1 Solution: Staircase & Lift
High Quality Danish Product
Indoor & Outdoor Use
Easy To Integrate In Both New & Existing Buildings
Plug-And-Play Installation
Integrated Machinery
Multiple Design Options
Dimensions: 45" x 43.3" x 39.4"
Weight: 550 lbs
Weight Capacity: 881 lbs.
Warranty: Manufacturer 2 Years from the date of Installation.
Comfort & Safety
*Audible alarm tones: Acoustic alarm tones inform about all the lift’s movements.
*Overload protection: The weight on the platform must be evenly distributed. In case of overload the platform stops.
*Automatic onboard barrier: Optional Automatic on-board barrier to increase the feeling of security.
*Ramp / Roll-off Protection: In use as a wheelchair lift, the ramp unfolds so that the wheelchair user can gain access to the platform. The ramp is raised and locked before the FlexStep moves as a lift.
*Squeeze protection underneath the platform: A pressure plate under each step are connected to safety micro switches. This eliminates the risk of getting squeezed underneath the platform. If activated during downwards motion, the lift will stop and move approx. 2-3 cm upwards.
*No visible cables: All cables are integrated into the design of the lift.
*Battery backup: Batteries which supply the system with power in case of power break down.
*Emergency stop at the platform: The platform stops any unintended movement once the emergency stop is activated.
FlexStep:
*Please see the following notes regarding platform width and installation width.
*Please note that an additional 11.8" (300 mm) is needed for installation of the unit.
Unit Width:
Platform Width | Total Installation Width
27.55" (700 mm) | 39.35" (1000 mm)
31.5" (800 mm) | 43.3" (1100 mm)
35.43" (900 mm) | 47.23" (1200 mm)
39.37" (1000 mm) | 51.17" (1300 mm)
*Platform length is determined by the number of steps.
Rise:
Minimum lifting height: 9.45" (240 mm)
Maximum lifting height: 49.2" (1250 mm)
Minimum rise needed for Automatic Vertical Barrier: 19.6" (500 mm) for a 1-Stop unit and 27.56" (700 mm) for a 2-Stop unit.
